{"id":7184638738592,"title":"Digital Multimeter Engine Analyzer, Auto-Ranging 6000 Counts Voltage Meter, Volt Ohm Amp DMM Tester, Injection Pulse, Dwell Angle, RMP Tester for Automotive Professionals (ANNMETER AN-770K)","handle":"digital-multimeter-engine-analyzer-auto-ranging-6000-counts-voltage-meter-volt-ohm-amp-dmm-tester-injection-pulse-dwell-angle-rmp-tester-for-automotive-professionals-annmeter-an-770k","description":"\u003ch3\u003eDigital Multimeter Engine Analyzer, Auto-Ranging 6000 Counts Voltage Meter, Volt Ohm Amp DMM Tester, Injection Pulse, Dwell Angle, RMP Tester for Automotive Professionals (ANNMETER AN-770K)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eANNMETER AN-770K is an ideal troubleshooter and Multimeter for DIY lovers and\nMechanics owing to the multifunctional design. ☞\nSpecifications:Weight:0.77IbSize:7.67x3.46x1.57inch Cap: 9.999nF~99.99mF\nFrequency: 9.999Hz~9.999mHz AC: 600mV\/6V\/60V\/600V\/750V DC:\n600mV\/6V\/60V\/600V\/1000V AC Current: 60mA\/600mA\/20A DC Current:\n600μA\/6000μA\/60mA\/600mA\/6A\/20A Duty Cycle: 1%~99.9%(+\/- 2%+5 ) Injection\nPulse: 0.1ms~10.0ms(+\/-2%+20) Dwell Angle: 0-90.0°,0-72.0°,0-60.0°,0-45.0°\nResistance: 600Ω\/6KΩ\/60KΩ\/600KΩ\/6MΩ\/60MΩ Tach (Rotate Speed): 600~12000 RPM\n(+\/-2.5% + 10) Temperature: -4~1832 ℉(-20~1000 ℃) Temperature probe included ☞\nFunction Overview: AC TRMS Peak Hold Data Hold Diode Test MAX\/MIN Value Auto\nShut Down Continuity Buzzer Auto Backlit Display LED Dial Indicator Ligh Non-\ncontact Voltage Test Auto\/ Manual Range Switchable Degrees Celsius \/\nFahrenheit Switchable AC Voltage or Current Peak Hold function Test\nmillisecond pulse width measurements for fuel injectors Negative or positive\npeaks capturing in 1.28-millisecond pulse width NOTE: Inductive Clamp Couple\nfor RPM NOT included. ☞ What You Get? 1 Test Lead 1 Alligator clip 1 Temp\nProbe 1 Instruction 1 AN-770K Automotive Multimeter\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003ePRO ENGINE ANALYZERAN-770K Engine analyzer flawlessly performs standard automotive-specific tests for on-car and on-bench troubleshooting, including: injection pulse, tach, dwell, RPM etc. Serving as a handy and professional tool for automotive professionals.\u003c\/li\u003e\n \u003cli\u003eVERSATILE MULTIMETER The meter has comprehensive electrical features to assist in professional work such as DC\/AC volts, current, amps, ohms, continuity, AC True RMS and diode tests. Added temperature switchable measuring function (F\/C).\u003c\/li\u003e\n \u003cli\u003eINTELLIGENT LCD INDICATION 6000 counts crystal clear LCD built with backlight sensor for automatically lighting up the screen in a relative dim or dark condition without needing to press on any button. Easy to read and operate.\u003c\/li\u003e\n \u003cli\u003eFULL AUTO METER The auto ranging, auto back-light, and auto shutdown function make it easier to troubleshoot the automotive and electrical problems. Magnet design allows you to attach the meter to the metal surface for convenient measuring.\u003c\/li\u003e\n \u003cli\u003eDURABLE \u0026amp; SAFE Anti-dropping rubber design prevent the digital engine tester from accidentally falling. Worry-free use with overload protection. ANNMETER also offers 12 months warranty and life-long technical support, shop with confidence!\u003c\/li\u003e\n \u003c\/ul\u003e\n\n\n\n\n","published_at":"2021-12-29T12:21:45+11:00","created_at":"2021-12-20T06:57:12+11:00","vendor":"AIOMEST","type":"Multimeters \u0026 Analyzers","tags":["cocoon"],"price":24500,"price_min":24500,"price_max":24500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":41495376953504,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B088R2KYL3","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Digital Multimeter Engine Analyzer, Auto-Ranging 6000 Counts Voltage Meter, Volt Ohm Amp DMM Tester, Injection Pulse, Dwell Angle, RMP Tester for Automotive Professionals (ANNMETER AN-770K)","public_title":null,"options":["Default Title"],"price":24500,"weight":637,"compare_at_price":null,"inventory_management":null,"barcode":"021467076773","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B088R2KYL3.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/71jUSJ_yIuL.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/61nRCvqZPnL.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/71cVHQO_TVL.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/71V7IGo-d8L.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/71rE7-k1pWL.jpg?v=1639943832","\/\/dingoship.com.au\/cdn\/shop\/products\/71844rL8rpL.jpg?v=1639943832"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B088R2KYL3.jpg?v=1639943832","options":["Title"],"media":[{"alt":null,"id":23608388354208,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B088R2KYL3.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B088R2KYL3.jpg?v=1639943832","width":1300},{"alt":null,"id":23608388386976,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71jUSJ_yIuL.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71jUSJ_yIuL.jpg?v=1639943832","width":1300},{"alt":null,"id":23608388419744,"position":3,"preview_image":{"aspect_ratio":1.029,"height":1162,"width":1196,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61nRCvqZPnL.jpg?v=1639943832"},"aspect_ratio":1.029,"height":1162,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61nRCvqZPnL.jpg?v=1639943832","width":1196},{"alt":null,"id":23608388452512,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71cVHQO_TVL.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71cVHQO_TVL.jpg?v=1639943832","width":1300},{"alt":null,"id":23608388485280,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71V7IGo-d8L.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71V7IGo-d8L.jpg?v=1639943832","width":1300},{"alt":null,"id":23608388518048,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71rE7-k1pWL.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71rE7-k1pWL.jpg?v=1639943832","width":1300},{"alt":null,"id":23608388550816,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71844rL8rpL.jpg?v=1639943832"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71844rL8rpL.jpg?v=1639943832","width":1300}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eDigital Multimeter Engine Analyzer, Auto-Ranging 6000 Counts Voltage Meter, Volt Ohm Amp DMM Tester, Injection Pulse, Dwell Angle, RMP Tester for Automotive Professionals (ANNMETER AN-770K)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eANNMETER AN-770K is an ideal troubleshooter and Multimeter for DIY lovers and\nMechanics owing to the multifunctional design. ☞\nSpecifications:Weight:0.77IbSize:7.67x3.46x1.57inch Cap: 9.999nF~99.99mF\nFrequency: 9.999Hz~9.999mHz AC: 600mV\/6V\/60V\/600V\/750V DC:\n600mV\/6V\/60V\/600V\/1000V AC Current: 60mA\/600mA\/20A DC Current:\n600μA\/6000μA\/60mA\/600mA\/6A\/20A Duty Cycle: 1%~99.9%(+\/- 2%+5 ) Injection\nPulse: 0.1ms~10.0ms(+\/-2%+20) Dwell Angle: 0-90.0°,0-72.0°,0-60.0°,0-45.0°\nResistance: 600Ω\/6KΩ\/60KΩ\/600KΩ\/6MΩ\/60MΩ Tach (Rotate Speed): 600~12000 RPM\n(+\/-2.5% + 10) Temperature: -4~1832 ℉(-20~1000 ℃) Temperature probe included ☞\nFunction Overview: AC TRMS Peak Hold Data Hold Diode Test MAX\/MIN Value Auto\nShut Down Continuity Buzzer Auto Backlit Display LED Dial Indicator Ligh Non-\ncontact Voltage Test Auto\/ Manual Range Switchable Degrees Celsius \/\nFahrenheit Switchable AC Voltage or Current Peak Hold function Test\nmillisecond pulse width measurements for fuel injectors Negative or positive\npeaks capturing in 1.28-millisecond pulse width NOTE: Inductive Clamp Couple\nfor RPM NOT included. ☞ What You Get? 1 Test Lead 1 Alligator clip 1 Temp\nProbe 1 Instruction 1 AN-770K Automotive Multimeter\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003ePRO ENGINE ANALYZERAN-770K Engine analyzer flawlessly performs standard automotive-specific tests for on-car and on-bench troubleshooting, including: injection pulse, tach, dwell, RPM etc. Serving as a handy and professional tool for automotive professionals.\u003c\/li\u003e\n \u003cli\u003eVERSATILE MULTIMETER The meter has comprehensive electrical features to assist in professional work such as DC\/AC volts, current, amps, ohms, continuity, AC True RMS and diode tests. Added temperature switchable measuring function (F\/C).\u003c\/li\u003e\n \u003cli\u003eINTELLIGENT LCD INDICATION 6000 counts crystal clear LCD built with backlight sensor for automatically lighting up the screen in a relative dim or dark condition without needing to press on any button. Easy to read and operate.\u003c\/li\u003e\n \u003cli\u003eFULL AUTO METER The auto ranging, auto back-light, and auto shutdown function make it easier to troubleshoot the automotive and electrical problems. Magnet design allows you to attach the meter to the metal surface for convenient measuring.\u003c\/li\u003e\n \u003cli\u003eDURABLE \u0026amp; SAFE Anti-dropping rubber design prevent the digital engine tester from accidentally falling. Worry-free use with overload protection. ANNMETER also offers 12 months warranty and life-long technical support, shop with confidence!\u003c\/li\u003e\n \u003c\/ul\u003e\n\n\n\n\n"}
