Features: 1. As a square wave signal generator, generates a square wave signal that is used for experimental development. 2. Used to drive a stepper motor to generate a square wave driving signal. 3. Generate an adjustable pulse for the MCU. 4. Generate an adjustable pulse to control the associated circuit. 5. Size: 31mm x 22mm 6. Main chip: NE555 7. Input voltage: 5V-15V DC. When the power supply is 5V, the output current can be 15MA. With 12V power supply, the output current can be 35 MA 8. Input current: ≥100 MA 9. Output amplitude: 4.2 V V-PP to 11.4 V V-PP. (Different input voltage, the output amplitude is different) 10. Maximum output current: ≥15mA (5V power supply, V-PP greater than 50%), ≥35mA (12V power supply, V-PP greater than 50%) 11. Output with LED display (low level, LED lights up; high level, LED turns off; low frequency, LED flashes) 12. The output frequency range is selectable: LF file: 1Hz ~ 50Hz IF file: 50Hz ~ 1kHz High frequency file: 1kHz ~ 10kHz RF file: 10kHz ~ 200kHz 13.The output duty cycle can be fine-tuned. Duty cycle and frequency cannot be set separately. Adjusting the duty cycle changes the frequency. Package contents: 5 x NE555 pulse frequency duty cycle adjustment module

Product Features

  • Main chip: N5555; Input voltage: DC5-15V; Output Amplitude: 4.2V V-PP (5V input) to 11.4V V-PP (12V input); Output frequency 1Hz-50Hz, 50Hz-1KHz, 1KHz-10KHz, 10KHz-200KHz Four optional.
  • The module has 4 jumpers and 2 variable resistors. Users can adjust the output wave with these components to easily obtain the ideal wave.
  • Output LED display,: low-level LED light, high-level LED off, the frequency is low when the LED flashes.
  • The capacitance determines the frequency range, the user can calculate the setting according to their own needs.
  • The output duty cycle can be fine-tuned. Duty cycle and frequency cannot be set separately. Adjusting the duty cycle changes the frequency.
