{"id":7407305687200,"title":"Electronics-Salon DIN Rail Mount 8 SPDT Power Relay Interface Module. (Operating Voltage: DC 5V) Operating Voltage: DC 5V","handle":"electronics-salon-din-rail-mount-8-spdt-power-relay-interface-module-operating-voltage-dc-5v-operating-voltage-dc-5v","description":"\u003ch3\u003eElectronics-Salon DIN Rail Mount 8 SPDT Power Relay Interface Module. (Operating Voltage: DC 5V)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDIN Rail mount 8 Channel 10Amp SPDT Power Relay Module, DC 5V Version.\nJS1-5V-F Power Relays. LED indicator for each relay channel. Darlington\ntransistors circuit driving relay, improve the reliability of action. DIN rail\nmount carrier: High quality Taiwan DINKLE fireproof nylon material DIN rail\nmount carrier (not China low quality carrier), can support width 35mm \/ 32mm \/\n15mm rail. FR-4 fiber glass dual layers PCB. High quality terminal block:\nPitch 5.0mm\/0.197\", Wire range 28AWG ~ 12AWG \/ 2.5mm square, Strip length 7mm.\nScrews - M2.5,steel,Cr3+ Zn plated. Pin header and Cage - Brass. External\ndimensions: 152 x 87 x 43mm(L x W x H).Operating Voltage \/ Current: DC 5V \/\n720mA. Input control signal voltage: 0V - 0.5Vdc, low level, relay not action.\n2.5V - 24Vdc, high level, relay action. Input control signal high level\ncurrent: 2.5V: 0.1mA. 5V: 0.35mA. 12V: 1.1mA. 20V: 1.9mA.Relay Specification:\nPart number: JS1-5V-F power relays. Contact Rating: 125VAC\/250VAC 10Amp or\n30VDC 5Amp.Wire connection: VCC: Power supply input. GND: Power supply ground\nand control signal ground. CH-x: Control signal input, Low: relay OFF, High:\nrelay ON. COM \/ NO \/ NC: (Cx=COMx) . Control signal state low, the relay OFF,\nCOM - NO disconnected, COM - NC connected. Control signal stage high, the\nrelay ON, COM - NO connected, COM - NC disconnected.This is a very simple\nmodule board, no paper specifications, any questions, feel free to tell me.\nDatasheet\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eDIN Rail mount 8 Channel 10Amp SPDT Power Relay Module, DC 5V Version.\u003c\/li\u003e\n \u003cli\u003eJS1-5V-F Power Relays. LED indicator for each relay channel. Darlington transistors circuit driving relay, improve the reliability of action.\u003c\/li\u003e\n \u003cli\u003eDIN rail mount carrier: High quality Taiwan DINKLE fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm \/ 32mm \/ 15mm rail. FR-4 fiber glass dual layers PCB.\u003c\/li\u003e\n \u003cli\u003eHigh quality terminal block: Pitch 5.0mm\/0.197\", Wire range 28AWG ~ 12AWG \/ 2.5mm square, Strip length 7mm. Screws - M2.5,steel,Cr3+ Zn plated. Pin header and Cage - Brass.\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-06-08T18:51:46+10:00","created_at":"2022-06-08T18:51:57+10:00","vendor":"Electronics-Salon","type":"IO Modules","tags":["dingo"],"price":25500,"price_min":25500,"price_max":25500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42167868063904,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B00M1MC3ZU","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Electronics-Salon DIN Rail Mount 8 SPDT Power Relay Interface Module. (Operating Voltage: DC 5V) Operating Voltage: DC 5V","public_title":null,"options":["Default Title"],"price":25500,"weight":322,"compare_at_price":null,"inventory_management":null,"barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B00M1MC3ZU.jpg?v=1654732667","\/\/dingoship.com.au\/cdn\/shop\/products\/713KT1PwrhL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/71ETUKDEsgL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/71X35MRJPEL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/81FwGstgOKL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/71gfanxI9NL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/71pJcEVYGPL.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/81Aj-2BAz2L.jpg?v=1654678317","\/\/dingoship.com.au\/cdn\/shop\/products\/716Bi-XV9fL.jpg?v=1654678317"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B00M1MC3ZU.jpg?v=1654732667","options":["Title"],"media":[{"alt":null,"id":24824205148320,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B00M1MC3ZU.jpg?v=1654732667"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B00M1MC3ZU.jpg?v=1654732667","width":1500},{"alt":null,"id":24819006865568,"position":2,"preview_image":{"aspect_ratio":0.812,"height":1500,"width":1218,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/713KT1PwrhL.jpg?v=1654678317"},"aspect_ratio":0.812,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/713KT1PwrhL.jpg?v=1654678317","width":1218},{"alt":null,"id":24819006898336,"position":3,"preview_image":{"aspect_ratio":2.174,"height":690,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71ETUKDEsgL.jpg?v=1654678317"},"aspect_ratio":2.174,"height":690,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71ETUKDEsgL.jpg?v=1654678317","width":1500},{"alt":null,"id":24819006931104,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71X35MRJPEL.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71X35MRJPEL.jpg?v=1654678317","width":1500},{"alt":null,"id":24819006963872,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/81FwGstgOKL.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/81FwGstgOKL.jpg?v=1654678317","width":1500},{"alt":null,"id":24819006996640,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71gfanxI9NL.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71gfanxI9NL.jpg?v=1654678317","width":1500},{"alt":null,"id":24819007029408,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1449,"width":1449,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71pJcEVYGPL.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1449,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71pJcEVYGPL.jpg?v=1654678317","width":1449},{"alt":null,"id":24819007062176,"position":8,"preview_image":{"aspect_ratio":1.0,"height":1274,"width":1274,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/81Aj-2BAz2L.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1274,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/81Aj-2BAz2L.jpg?v=1654678317","width":1274},{"alt":null,"id":24819007094944,"position":9,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/716Bi-XV9fL.jpg?v=1654678317"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/716Bi-XV9fL.jpg?v=1654678317","width":1500}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eElectronics-Salon DIN Rail Mount 8 SPDT Power Relay Interface Module. (Operating Voltage: DC 5V)\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDIN Rail mount 8 Channel 10Amp SPDT Power Relay Module, DC 5V Version.\nJS1-5V-F Power Relays. LED indicator for each relay channel. Darlington\ntransistors circuit driving relay, improve the reliability of action. DIN rail\nmount carrier: High quality Taiwan DINKLE fireproof nylon material DIN rail\nmount carrier (not China low quality carrier), can support width 35mm \/ 32mm \/\n15mm rail. FR-4 fiber glass dual layers PCB. High quality terminal block:\nPitch 5.0mm\/0.197\", Wire range 28AWG ~ 12AWG \/ 2.5mm square, Strip length 7mm.\nScrews - M2.5,steel,Cr3+ Zn plated. Pin header and Cage - Brass. External\ndimensions: 152 x 87 x 43mm(L x W x H).Operating Voltage \/ Current: DC 5V \/\n720mA. Input control signal voltage: 0V - 0.5Vdc, low level, relay not action.\n2.5V - 24Vdc, high level, relay action. Input control signal high level\ncurrent: 2.5V: 0.1mA. 5V: 0.35mA. 12V: 1.1mA. 20V: 1.9mA.Relay Specification:\nPart number: JS1-5V-F power relays. Contact Rating: 125VAC\/250VAC 10Amp or\n30VDC 5Amp.Wire connection: VCC: Power supply input. GND: Power supply ground\nand control signal ground. CH-x: Control signal input, Low: relay OFF, High:\nrelay ON. COM \/ NO \/ NC: (Cx=COMx) . Control signal state low, the relay OFF,\nCOM - NO disconnected, COM - NC connected. Control signal stage high, the\nrelay ON, COM - NO connected, COM - NC disconnected.This is a very simple\nmodule board, no paper specifications, any questions, feel free to tell me.\nDatasheet\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eDIN Rail mount 8 Channel 10Amp SPDT Power Relay Module, DC 5V Version.\u003c\/li\u003e\n \u003cli\u003eJS1-5V-F Power Relays. LED indicator for each relay channel. Darlington transistors circuit driving relay, improve the reliability of action.\u003c\/li\u003e\n \u003cli\u003eDIN rail mount carrier: High quality Taiwan DINKLE fireproof nylon material DIN rail mount carrier (not China low quality carrier), can support width 35mm \/ 32mm \/ 15mm rail. FR-4 fiber glass dual layers PCB.\u003c\/li\u003e\n \u003cli\u003eHigh quality terminal block: Pitch 5.0mm\/0.197\", Wire range 28AWG ~ 12AWG \/ 2.5mm square, Strip length 7mm. Screws - M2.5,steel,Cr3+ Zn plated. Pin header and Cage - Brass.\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
