{"id":7417404326048,"title":"Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/BY Detection 10mm 10-30VDC 200mA PNP Normally Open(NO) 3 Wires","handle":"heschen-m18-capacitive-proximity-sensor-switch-non-shield-type-ljc18a3-b-z-by-detection-10mm-10-30vdc-200ma-pnp-normally-openno-3-wires","description":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/BY Detection 10mm 10-30VDC 200mA PNP Normally Open(NO) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(10-30V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:200mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 10mm10%; Set distance:0-8mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: PNP Normally Open(NO), Non-Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30 VDC\u003c\/li\u003e\n \u003cli\u003eCable Length: 50\"(127cm)\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-10-26T14:56:54+11:00","created_at":"2022-06-16T22:10:13+10:00","vendor":"Heschen","type":"Capacitive","tags":["dingo"],"price":10900,"price_min":10900,"price_max":10900,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42211060383904,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0714JVD68","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/BY Detection 10mm 10-30VDC 200mA PNP Normally Open(NO) 3 Wires","public_title":null,"options":["Default Title"],"price":10900,"weight":90,"compare_at_price":null,"inventory_management":null,"barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B0714JVD68.jpg?v=1655425191","\/\/dingoship.com.au\/cdn\/shop\/products\/61YEa9cWLmL_c379eb16-e444-48ce-abc4-53afb7af790b.jpg?v=1655381413","\/\/dingoship.com.au\/cdn\/shop\/products\/61d7wU5iB-L_0a19b4b4-f351-4876-bc58-601408d2c5ea.jpg?v=1655381413","\/\/dingoship.com.au\/cdn\/shop\/products\/61-Xh4cz-mL_bd6d18b2-dc8d-4fb3-914e-13e3c2380100.jpg?v=1655381413","\/\/dingoship.com.au\/cdn\/shop\/products\/61jOnss_ML.jpg?v=1655381413","\/\/dingoship.com.au\/cdn\/shop\/products\/61bYYQOT_sL.jpg?v=1655381413","\/\/dingoship.com.au\/cdn\/shop\/products\/61lQEkWhp8L_58c9b82b-376b-447b-9d28-de89e9090003.jpg?v=1655381413"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0714JVD68.jpg?v=1655425191","options":["Title"],"media":[{"alt":null,"id":24872235434144,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0714JVD68.jpg?v=1655425191"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0714JVD68.jpg?v=1655425191","width":1300},{"alt":null,"id":24869321343136,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61YEa9cWLmL_c379eb16-e444-48ce-abc4-53afb7af790b.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61YEa9cWLmL_c379eb16-e444-48ce-abc4-53afb7af790b.jpg?v=1655381413","width":1300},{"alt":null,"id":24869321375904,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61d7wU5iB-L_0a19b4b4-f351-4876-bc58-601408d2c5ea.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61d7wU5iB-L_0a19b4b4-f351-4876-bc58-601408d2c5ea.jpg?v=1655381413","width":1300},{"alt":null,"id":24869321408672,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61-Xh4cz-mL_bd6d18b2-dc8d-4fb3-914e-13e3c2380100.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61-Xh4cz-mL_bd6d18b2-dc8d-4fb3-914e-13e3c2380100.jpg?v=1655381413","width":1300},{"alt":null,"id":24869321441440,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61jOnss_ML.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61jOnss_ML.jpg?v=1655381413","width":1300},{"alt":null,"id":24869321474208,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61bYYQOT_sL.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61bYYQOT_sL.jpg?v=1655381413","width":1300},{"alt":null,"id":24869321506976,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61lQEkWhp8L_58c9b82b-376b-447b-9d28-de89e9090003.jpg?v=1655381413"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61lQEkWhp8L_58c9b82b-376b-447b-9d28-de89e9090003.jpg?v=1655381413","width":1300}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Non-Shield Type LJC18A3-B-Z\/BY Detection 10mm 10-30VDC 200mA PNP Normally Open(NO) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(10-30V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:200mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 10mm10%; Set distance:0-8mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: PNP Normally Open(NO), Non-Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30 VDC\u003c\/li\u003e\n \u003cli\u003eCable Length: 50\"(127cm)\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
