{"id":7418277036192,"title":"Heschen M18 Capacitive Proximity Sensor Switch Shield Type LJC18A3-5-Z\/BX Detection 5mm 10-30VDC 200mA NPN Normally Open(NO) 3 Wires","handle":"heschen-m18-capacitive-proximity-sensor-switch-shield-type-ljc18a3-5-z-bx-detection-5mm-10-30vdc-200ma-npn-normally-openno-3-wires","description":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Shield Type LJC18A3-5-Z\/BX Detection 5mm 10-30VDC 200mA NPN Normally Open(NO) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(6-36V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:300mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 5mm10%; Set distance:0-4mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: NPN Normally Open(NO); Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30 VDC\u003c\/li\u003e\n \u003cli\u003eDetection Object:Can detect any dielectric\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-06-17T23:44:54+10:00","created_at":"2022-06-17T23:45:01+10:00","vendor":"Heschen","type":"Proximity Sensors","tags":["dingo"],"price":10800,"price_min":10800,"price_max":10800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42214905610400,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B07XKFX1HR","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen M18 Capacitive Proximity Sensor Switch Shield Type LJC18A3-5-Z\/BX Detection 5mm 10-30VDC 200mA NPN Normally Open(NO) 3 Wires","public_title":null,"options":["Default Title"],"price":10800,"weight":90,"compare_at_price":null,"inventory_management":null,"barcode":"HS-LJC18A3-5-Z\/BX","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B07XKFX1HR.jpg?v=1655508373","\/\/dingoship.com.au\/cdn\/shop\/products\/61Djts_BWzL.jpg?v=1655473501","\/\/dingoship.com.au\/cdn\/shop\/products\/61cIi8alXDL.jpg?v=1655473501","\/\/dingoship.com.au\/cdn\/shop\/products\/71hOfTbSNLL.jpg?v=1655473501","\/\/dingoship.com.au\/cdn\/shop\/products\/61zuhSYegzL.jpg?v=1655473501","\/\/dingoship.com.au\/cdn\/shop\/products\/71YVA0fFhUL.jpg?v=1655473501"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B07XKFX1HR.jpg?v=1655508373","options":["Title"],"media":[{"alt":null,"id":24876904906912,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B07XKFX1HR.jpg?v=1655508373"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B07XKFX1HR.jpg?v=1655508373","width":1300},{"alt":null,"id":24874497507488,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Djts_BWzL.jpg?v=1655473501"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Djts_BWzL.jpg?v=1655473501","width":1300},{"alt":null,"id":24874497540256,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61cIi8alXDL.jpg?v=1655473501"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61cIi8alXDL.jpg?v=1655473501","width":1300},{"alt":null,"id":24874497573024,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71hOfTbSNLL.jpg?v=1655473501"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71hOfTbSNLL.jpg?v=1655473501","width":1300},{"alt":null,"id":24874497605792,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61zuhSYegzL.jpg?v=1655473501"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61zuhSYegzL.jpg?v=1655473501","width":1300},{"alt":null,"id":24874497638560,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71YVA0fFhUL.jpg?v=1655473501"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71YVA0fFhUL.jpg?v=1655473501","width":1300}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen M18 Capacitive Proximity Sensor Switch Shield Type LJC18A3-5-Z\/BX Detection 5mm 10-30VDC 200mA NPN Normally Open(NO) 3 Wires\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eDetection Object:Can detect any dielectric.Delay Distance:10% below of the\ndetection distance.Supply Voltage:DC12-24V(6-36V) Impulse (p-p)10%\nbelow.Comsuption Current:13mA below.Control Output:300mA below.Loop Protection\n:reversal connection protection,surge absorption,load short-circuit\nprotection.Ambient Temperature \u0026amp; Humidity:During operation , storage :\nindividually-30～＋65℃(no freeze ,no drew ) ,During\noperation,storage:individually 35-95%RH.Insulation Impedance :50MΩ above (\nDC500 megameter ) between charging part and shell.Withstand Voltage : AC1000V\n50\/60Hz 1 min. between charging part and shell.Temperature Influence :\nTemperature range-30～＋65℃,at + 23℃,± 15% detection distance, Temperature\nrange-25～＋60℃,at +23℃,±10% detection distance.Voltage influence : Inside ±I5%\nrated supply voltage range,at rated supply voltage value ,inside ± 10 %\ndetection distance.\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eMounting Hole Diameter: 18mm\u003c\/li\u003e\n \u003cli\u003eDetecting Distance: 5mm10%; Set distance:0-4mm\u003c\/li\u003e\n \u003cli\u003eOutput Type: NPN Normally Open(NO); Shield Type\u003c\/li\u003e\n \u003cli\u003eCurrent Output: 200mA; Working Voltage: 10-30 VDC\u003c\/li\u003e\n \u003cli\u003eDetection Object:Can detect any dielectric\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
