{"id":12639863177376,"title":"Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS100P2, Detection Distance 10-100CM, 10-30VDC 200mA, PNP Normally Closed (NC), 3 Wires","handle":"heschen-m18-column-infrared-photoelectric-proximity-switch-diffuse-reflection-type-e3f-ds100p2-detection-distance-10-100cm-10-30vdc-200ma-pnp-normally-closed-nc-3-wires","description":"\u003ch3\u003eHeschen M18 column infrared photoelectric proximity switch, diffuse reflection type, E3F-DS100P2, detection distance 10-100CM, 10-30VDC 200mA, PNP normally closed (NC), 3 wires\u003c\/h3\u003e \u003cp id=\"b\"\u003eConnection delay: 1.5ms. Light source: infrared light 660 nm. Supply voltage: DC 10-30V pulse (pp) 10% under current: 20 mA below. Control output: 200 mA below. Loop protection: reversal protection, over-voltage attenuation, load short circuit protection. Ambient temperature and humidity: during operation, storage: individual 30 ~ + 65 ° C (no freezing, no Drew), during operation, storage: individual 35 - 95% relative humidity. Insulation impedance: 50 MΩ above (DC500 megameters) between charging part and housing. Dielectric strength: AC 1000 V, 50\/60 Hz, 1 min between charging unit and housing. Temperature influence: Temperature range: 30 ~ + 65 °C, at + 23 °C, ± 15% detection distance, Temperature range: 25 ~ + 60 °C, at +23 °C, ± 10% detection distance. Voltage influence: Inside ± 15% rated supply voltage range, at rated supply voltage value, within ± 10% detection distance.\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eMounting hole diameter: 18 mm; Cable length: 150 cm\u003c\/li\u003e \u003cli\u003eDetection distance: 10100 cm 10%, adjustable\u003c\/li\u003e \u003cli\u003eOutput type: PNP Normal Closed(NC); diffuse reflection type\u003c\/li\u003e \u003cli\u003eCurrent output: 200 mA; Operating voltage: 1030 V DC\u003c\/li\u003e \u003cli\u003eDetection target: opaque object\u003c\/li\u003e \u003c\/ul\u003e","published_at":"2024-03-07T01:24:32+11:00","created_at":"2024-03-07T01:24:39+11:00","vendor":"Heschen","type":"Photoelectric sensors","tags":["industryDE"],"price":13400,"price_min":13400,"price_max":13400,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":48971845075104,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0B1WLYHMT","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Heschen M18 Column Infrared Photoelectric Proximity Switch, Diffuse Reflection Type, E3F-DS100P2, Detection Distance 10-100CM, 10-30VDC 200mA, PNP Normally Closed (NC), 3 Wires","public_title":null,"options":["Default Title"],"price":13400,"weight":70,"compare_at_price":null,"inventory_management":"shopify","barcode":"HS-E3F-DS100P2","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0B1WLYHMT.jpg?v=1709767408","\/\/dingoship.com.au\/cdn\/shop\/products\/51BdRXk4f-L.jpg?v=1709735079","\/\/dingoship.com.au\/cdn\/shop\/products\/51926sJ0wEL.jpg?v=1709735079","\/\/dingoship.com.au\/cdn\/shop\/products\/61JlIzHsSwL.jpg?v=1709735079","\/\/dingoship.com.au\/cdn\/shop\/products\/61Ms7TQJK9L.jpg?v=1709735079"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0B1WLYHMT.jpg?v=1709767408","options":["Title"],"media":[{"alt":null,"id":32683020615840,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0B1WLYHMT.jpg?v=1709767408"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0B1WLYHMT.jpg?v=1709767408","width":1200},{"alt":null,"id":32675651780768,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51BdRXk4f-L.jpg?v=1709735079"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51BdRXk4f-L.jpg?v=1709735079","width":1200},{"alt":null,"id":32675651813536,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1200,"width":1200,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51926sJ0wEL.jpg?v=1709735079"},"aspect_ratio":1.0,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51926sJ0wEL.jpg?v=1709735079","width":1200},{"alt":null,"id":32675651846304,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61JlIzHsSwL.jpg?v=1709735079"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61JlIzHsSwL.jpg?v=1709735079","width":1300},{"alt":null,"id":32675651879072,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1300,"width":1300,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Ms7TQJK9L.jpg?v=1709735079"},"aspect_ratio":1.0,"height":1300,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Ms7TQJK9L.jpg?v=1709735079","width":1300}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHeschen M18 column infrared photoelectric proximity switch, diffuse reflection type, E3F-DS100P2, detection distance 10-100CM, 10-30VDC 200mA, PNP normally closed (NC), 3 wires\u003c\/h3\u003e \u003cp id=\"b\"\u003eConnection delay: 1.5ms. Light source: infrared light 660 nm. Supply voltage: DC 10-30V pulse (pp) 10% under current: 20 mA below. Control output: 200 mA below. Loop protection: reversal protection, over-voltage attenuation, load short circuit protection. Ambient temperature and humidity: during operation, storage: individual 30 ~ + 65 ° C (no freezing, no Drew), during operation, storage: individual 35 - 95% relative humidity. Insulation impedance: 50 MΩ above (DC500 megameters) between charging part and housing. Dielectric strength: AC 1000 V, 50\/60 Hz, 1 min between charging unit and housing. Temperature influence: Temperature range: 30 ~ + 65 °C, at + 23 °C, ± 15% detection distance, Temperature range: 25 ~ + 60 °C, at +23 °C, ± 10% detection distance. Voltage influence: Inside ± 15% rated supply voltage range, at rated supply voltage value, within ± 10% detection distance.\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eMounting hole diameter: 18 mm; Cable length: 150 cm\u003c\/li\u003e \u003cli\u003eDetection distance: 10100 cm 10%, adjustable\u003c\/li\u003e \u003cli\u003eOutput type: PNP Normal Closed(NC); diffuse reflection type\u003c\/li\u003e \u003cli\u003eCurrent output: 200 mA; Operating voltage: 1030 V DC\u003c\/li\u003e \u003cli\u003eDetection target: opaque object\u003c\/li\u003e \u003c\/ul\u003e"}
