{"id":12965759254688,"title":"Household AC Contactor 2P 20A 24V 220V\/230V 50\/60Hz Household AC Contactor 2 Pin DIN Rail Mount 1NO 1NC (220V\/230V) Mount 220V\/230V","handle":"household-ac-contactor-2p-20a-24v-220v-230v-50-60hz-household-ac-contactor-2-pin-din-rail-mount-1no-1nc-220v-230v-mount-220v-230v","description":"\u003ch3\u003eHousehold AC Contactor 2P 20A 24V 220V\/230V 50\/60Hz Household AC Contactor 2 Pin DIN Rail Mount 1NO 1NC (220V\/230V) Mounting\u003c\/h3\u003e \u003cp id=\"b\"\u003eTechnical Data: Rated control supply voltage (Us): AC 24 V, AC 220 V \/ 230 V (optional) Rated current: 20 A (AC-7a), 7 A (AC-7b) Conventional thermal current (lth): 25A Rated insulation voltage (Ui): 500VAC Rated operating voltage (Ue): 400VAC Number of poles: 2P (1NO + 1NC) Maximum number of switching cycles: 30 times \/ hour Electrical life: 100,000 times Mechanical life: 1,000,000 times Package weight: approx. 128 g Rated power: 1) 8 hours service This is The base load and the conventional heating current Ith of the contactor are determined by this working system. 2) Intermittent operation The nominal switching frequency of the contactor in this operation is 30 times \/ h and the utilization rate is 40%. Action Condition (Operation): When the ambient temperature is in the range of -5°C to +60°C, apply the rated supply voltage of the Us control to the suction coil of the contactor. To heat it to a stable state, the contactor must be under any voltage of (85% ~ 110%) Us can be reliably closed. The trigger voltage is (20% ~ 75%) Us. Package List: 1 AC Contactor\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eSAFE OPERATION: This AC protector for home use uses high quality insulation material to improve operational safety. \u003c\/li\u003e \u003cli\u003eHIGH QUALITY: This AC home protector is 100% brand new and high quality, designed for home use, 35mm DIN rail mounting.\u003c\/li\u003e \u003cli\u003eEASY TO INSTALL: The compact and modular design makes this AC protector easy to install and saves space.\u003c\/li\u003e \u003cli\u003eCIRCUIT DIAGRAM: There is a circuit diagram printed on the surface of the protector.\u003c\/li\u003e \u003cli\u003eAPPLICATIONS: This AC home protector is suitable for the most building control applications and operates quietly to create a quiet environment.\u003c\/li\u003e\n\u003c\/ul\u003e","published_at":"2024-04-07T03:19:33+10:00","created_at":"2024-04-07T03:19:43+10:00","vendor":"Hilitand","type":"Motor contactor","tags":["industryDE"],"price":17100,"price_min":17100,"price_max":17100,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":49430413508768,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B07VRN9DQ6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Household AC Contactor 2P 20A 24V 220V\/230V 50\/60Hz Household AC Contactor 2 Pin DIN Rail Mount 1NO 1NC (220V\/230V) Mount 220V\/230V","public_title":null,"options":["Default Title"],"price":17100,"weight":700,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/files\/de-B07VRN9DQ6.jpg?v=1712445852","\/\/dingoship.com.au\/cdn\/shop\/files\/51oM0c2GIAL_3491b206-a58b-4d04-a486-1b8c63298036.jpg?v=1712423983","\/\/dingoship.com.au\/cdn\/shop\/files\/41zVpBbgRKL.jpg?v=1712423983","\/\/dingoship.com.au\/cdn\/shop\/files\/51Sl5KGvsYL.jpg?v=1712423983","\/\/dingoship.com.au\/cdn\/shop\/files\/41mlLVpelvL.jpg?v=1712423983","\/\/dingoship.com.au\/cdn\/shop\/files\/61McYHrQZyL.jpg?v=1712423983","\/\/dingoship.com.au\/cdn\/shop\/files\/51HIaL5VimL.jpg?v=1712423983"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B07VRN9DQ6.jpg?v=1712445852","options":["Title"],"media":[{"alt":null,"id":33793426882720,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B07VRN9DQ6.jpg?v=1712445852"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B07VRN9DQ6.jpg?v=1712445852","width":1601},{"alt":null,"id":33789433479328,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51oM0c2GIAL_3491b206-a58b-4d04-a486-1b8c63298036.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51oM0c2GIAL_3491b206-a58b-4d04-a486-1b8c63298036.jpg?v=1712423983","width":1601},{"alt":null,"id":33789433512096,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/41zVpBbgRKL.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/41zVpBbgRKL.jpg?v=1712423983","width":1601},{"alt":null,"id":33789433544864,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51Sl5KGvsYL.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51Sl5KGvsYL.jpg?v=1712423983","width":1601},{"alt":null,"id":33789433577632,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/41mlLVpelvL.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/41mlLVpelvL.jpg?v=1712423983","width":1601},{"alt":null,"id":33789433610400,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61McYHrQZyL.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61McYHrQZyL.jpg?v=1712423983","width":1601},{"alt":null,"id":33789433643168,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51HIaL5VimL.jpg?v=1712423983"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51HIaL5VimL.jpg?v=1712423983","width":1601}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eHousehold AC Contactor 2P 20A 24V 220V\/230V 50\/60Hz Household AC Contactor 2 Pin DIN Rail Mount 1NO 1NC (220V\/230V) Mounting\u003c\/h3\u003e \u003cp id=\"b\"\u003eTechnical Data: Rated control supply voltage (Us): AC 24 V, AC 220 V \/ 230 V (optional) Rated current: 20 A (AC-7a), 7 A (AC-7b) Conventional thermal current (lth): 25A Rated insulation voltage (Ui): 500VAC Rated operating voltage (Ue): 400VAC Number of poles: 2P (1NO + 1NC) Maximum number of switching cycles: 30 times \/ hour Electrical life: 100,000 times Mechanical life: 1,000,000 times Package weight: approx. 128 g Rated power: 1) 8 hours service This is The base load and the conventional heating current Ith of the contactor are determined by this working system. 2) Intermittent operation The nominal switching frequency of the contactor in this operation is 30 times \/ h and the utilization rate is 40%. Action Condition (Operation): When the ambient temperature is in the range of -5°C to +60°C, apply the rated supply voltage of the Us control to the suction coil of the contactor. To heat it to a stable state, the contactor must be under any voltage of (85% ~ 110%) Us can be reliably closed. The trigger voltage is (20% ~ 75%) Us. Package List: 1 AC Contactor\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eSAFE OPERATION: This AC protector for home use uses high quality insulation material to improve operational safety. \u003c\/li\u003e \u003cli\u003eHIGH QUALITY: This AC home protector is 100% brand new and high quality, designed for home use, 35mm DIN rail mounting.\u003c\/li\u003e \u003cli\u003eEASY TO INSTALL: The compact and modular design makes this AC protector easy to install and saves space.\u003c\/li\u003e \u003cli\u003eCIRCUIT DIAGRAM: There is a circuit diagram printed on the surface of the protector.\u003c\/li\u003e \u003cli\u003eAPPLICATIONS: This AC home protector is suitable for the most building control applications and operates quietly to create a quiet environment.\u003c\/li\u003e\n\u003c\/ul\u003e"}
