{"id":7618594832544,"title":"OSOYOO 1x Pro Micro Board Mega32U4 Leonardo 5V\/16MHz Module Board Type C Port for Arduino x1 Pro micro","handle":"osoyoo-1x-pro-micro-board-mega32u4-leonardo-5v-16mhz-module-board-type-c-port-for-arduino-x1-pro-micro","description":"\u003ch3\u003eOSOYOO 1x Pro Micro Board Mega32U4 Leonardo 5V\/16MHz Module Board Type C Port for Arduino\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eATmega32U4 running at 5V\/16MHz The ATmega32U4 chip on the\nPro Micro board comes preprogrammed with a bootloader that allows you to\nupload new code to it without the use of an external hardware programmer.it\nrunning at 5V\/16MHz and the maximum voltage allowed on the RAW pin is 9V, 6-7V\ninput recommended. Read more Multi-channels There are 4 channels of 10-bit\nADC, 5 PWM pins, 12 DIOs as well as hardware serial connections RX and TX on\nPro Micro. This board will remind you a lot of your other favorite Arduino-\ncompatible boards but this little guy can go just about anywhere. Read more\nUSB-C connection The pro micro board can be powered via the USB-C connection\nor with an external power supply. The power source is selected\nautomatically.The Micro appears as a generic keyboard and mouse, and can be\nprogrammed to control these input devices using the keyboard and mouse\nclasses. The Pro Micro is powered with an external power supply(not via the\nUSB-C connection),please be sure to make the power connect to the \"raw\" pin\nand the ground to GND. Read more Voltage regulator chip There is a voltage\nregulator on board so it can accept voltage up to 9V DC.The maximum voltage\nallowed on the RAW pin is 9V, 6-7V input recommended. If you're supplying\nunregulated power to the board, be sure to connect to the \"RAW\" pin on not\nVCC. Read more\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSB USB-C Port Reinforced-This is latest the USB-C port reinforced and make it more stronger solder points.\u003c\/li\u003e\n \u003cli\u003eATmega32U4 microcontroller-The Pro Micro is similar to the Pro Mini except with an ATmega32U4 on board. The USB type C transceiver inside the 32U4 allows us to add type C connectivity on-board and do away with bulky external type C interface.\u003c\/li\u003e\n \u003cli\u003eMulti-channels-This tiny little board does all of the neat tricks that you're familiar with: 9 channels of 10-bit ADC, 5 PWM pins,12 DIOs as well as hardware serial connections Rx and Tx. Running at 16MHz and 5V, this board will remind you a lot of your other favorite Arduino-compatible boards but this little guy can go just about anywhere.\u003c\/li\u003e\n \u003cli\u003eVoltage regulator-There is a voltage regulator on board so it can accept voltage up to 9V DC.The maximum voltage allowed on the RAW pin is 9V, 6-7V input recommended. If you're supplying unregulated power to the board, be sure to connect to the \"RAW\" pin on not VCC.\u003c\/li\u003e\n \u003cli\u003eAnti-ESD PackageThe boards came in a box package with a pinout diagram printed on, each in their own anti-ESD(Electronic Static Discharge) bag with 3 rows of header pins.\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n","published_at":"2022-11-25T17:52:46+11:00","created_at":"2022-11-25T17:52:53+11:00","vendor":"OSOYOO","type":"","tags":["electronics_new_Nov2022"],"price":11500,"price_min":11500,"price_max":11500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42803405848736,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0B81FGBLY","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"OSOYOO 1x Pro Micro Board Mega32U4 Leonardo 5V\/16MHz Module Board Type C Port for Arduino x1 Pro micro","public_title":null,"options":["Default Title"],"price":11500,"weight":14,"compare_at_price":null,"inventory_management":null,"barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B0B81FGBLY.jpg?v=1669419188","\/\/dingoship.com.au\/cdn\/shop\/products\/71PDKi3EgiL.jpg?v=1669359173","\/\/dingoship.com.au\/cdn\/shop\/products\/71LAoSewKZL.jpg?v=1669359173","\/\/dingoship.com.au\/cdn\/shop\/products\/61yacJP4ccL.jpg?v=1669359173","\/\/dingoship.com.au\/cdn\/shop\/products\/71J5y7kaveL.jpg?v=1669359173","\/\/dingoship.com.au\/cdn\/shop\/products\/71ETbmwovRL.jpg?v=1669359173"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0B81FGBLY.jpg?v=1669419188","options":["Title"],"media":[{"alt":null,"id":25893981520032,"position":1,"preview_image":{"aspect_ratio":1.0,"height":2308,"width":2308,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0B81FGBLY.jpg?v=1669419188"},"aspect_ratio":1.0,"height":2308,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B0B81FGBLY.jpg?v=1669419188","width":2308},{"alt":null,"id":25890154774688,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71PDKi3EgiL.jpg?v=1669359173"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71PDKi3EgiL.jpg?v=1669359173","width":1500},{"alt":null,"id":25890154807456,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71LAoSewKZL.jpg?v=1669359173"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71LAoSewKZL.jpg?v=1669359173","width":1500},{"alt":null,"id":25890154840224,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61yacJP4ccL.jpg?v=1669359173"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61yacJP4ccL.jpg?v=1669359173","width":1500},{"alt":null,"id":25890154872992,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71J5y7kaveL.jpg?v=1669359173"},"aspect_ratio":1.0,"height":1500,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71J5y7kaveL.jpg?v=1669359173","width":1500},{"alt":null,"id":25890154905760,"position":6,"preview_image":{"aspect_ratio":1.0,"height":2000,"width":2000,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71ETbmwovRL.jpg?v=1669359173"},"aspect_ratio":1.0,"height":2000,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/71ETbmwovRL.jpg?v=1669359173","width":2000}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eOSOYOO 1x Pro Micro Board Mega32U4 Leonardo 5V\/16MHz Module Board Type C Port for Arduino\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eATmega32U4 running at 5V\/16MHz The ATmega32U4 chip on the\nPro Micro board comes preprogrammed with a bootloader that allows you to\nupload new code to it without the use of an external hardware programmer.it\nrunning at 5V\/16MHz and the maximum voltage allowed on the RAW pin is 9V, 6-7V\ninput recommended. Read more Multi-channels There are 4 channels of 10-bit\nADC, 5 PWM pins, 12 DIOs as well as hardware serial connections RX and TX on\nPro Micro. This board will remind you a lot of your other favorite Arduino-\ncompatible boards but this little guy can go just about anywhere. Read more\nUSB-C connection The pro micro board can be powered via the USB-C connection\nor with an external power supply. The power source is selected\nautomatically.The Micro appears as a generic keyboard and mouse, and can be\nprogrammed to control these input devices using the keyboard and mouse\nclasses. The Pro Micro is powered with an external power supply(not via the\nUSB-C connection),please be sure to make the power connect to the \"raw\" pin\nand the ground to GND. Read more Voltage regulator chip There is a voltage\nregulator on board so it can accept voltage up to 9V DC.The maximum voltage\nallowed on the RAW pin is 9V, 6-7V input recommended. If you're supplying\nunregulated power to the board, be sure to connect to the \"RAW\" pin on not\nVCC. Read more\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eUSB USB-C Port Reinforced-This is latest the USB-C port reinforced and make it more stronger solder points.\u003c\/li\u003e\n \u003cli\u003eATmega32U4 microcontroller-The Pro Micro is similar to the Pro Mini except with an ATmega32U4 on board. The USB type C transceiver inside the 32U4 allows us to add type C connectivity on-board and do away with bulky external type C interface.\u003c\/li\u003e\n \u003cli\u003eMulti-channels-This tiny little board does all of the neat tricks that you're familiar with: 9 channels of 10-bit ADC, 5 PWM pins,12 DIOs as well as hardware serial connections Rx and Tx. Running at 16MHz and 5V, this board will remind you a lot of your other favorite Arduino-compatible boards but this little guy can go just about anywhere.\u003c\/li\u003e\n \u003cli\u003eVoltage regulator-There is a voltage regulator on board so it can accept voltage up to 9V DC.The maximum voltage allowed on the RAW pin is 9V, 6-7V input recommended. If you're supplying unregulated power to the board, be sure to connect to the \"RAW\" pin on not VCC.\u003c\/li\u003e\n \u003cli\u003eAnti-ESD PackageThe boards came in a box package with a pinout diagram printed on, each in their own anti-ESD(Electronic Static Discharge) bag with 3 rows of header pins.\u003c\/li\u003e\n \u003c\/ul\u003e\n\u003chr class=\"py-vbody\" style=\"display: none\"\u003e\n\n\n"}
