RPi GPIO Terminal Block Breakout Board HAT, for Raspberry Pi

In Stock. Leaves warehouse within 2 - 3 business days

126.00 AUD
Maximum quantity available reached.
Enter 5DINGO at Checkout for 5% OFF & Free Shipping in Australia
More detailed product descriptions
Free Shipping Australia Wide
100% Safe & Secure Checkout
100 Days Return Policy *
1 Year Warranty *

RPi GPIO Terminal Block Breakout Board HAT, for Raspberry Pi

1, The item has been soldered and assembled. Support for Raspberry Pi 1 Model B+, Pi 2 Model B, Pi 3 Model B, Pi 3 Model B+, Pi 4 Model B. 2, Terminal block pitch 3.5mm/0.138", wire size range 26AWG to 16AWG, strip length 5mm, screw M2 steel, pin header and cage copper. 3, FR-4 fiber glass PCB, dual copper layers. 4, 2 x 20 pins expansion pin header, height 10mm/0.39". 5, Packing list: 1x terminal block breakout module, 6x M2.5x6mm screws, 4x 14mm brass standoffs. (NOTE: the item not include Raspberry Pi Board).

Product Features

  • The item has been soldered and assembled. Support for Raspberry Pi 1 Model B+, Pi 2 Model B, Pi 3 Model B, Pi 3 Model B+, Pi 4 Model B.
  • Terminal block pitch 3.5mm/0.138", wire size range 26AWG to 16AWG, strip length 5mm, screw M2 steel, pin header and cage copper.
  • FR-4 fiber glass PCB, dual copper layers.
  • 2 x 20 pins expansion pin header, height 10mm/0.39".
  • Packing list: 1x terminal block breakout module, 6x M2.5x6mm screws, 4x 14mm brass standoffs. (NOTE: the item not include Raspberry Pi Board).
