{"id":12966292258976,"title":"SN04-N2 NPN Proximity Sensor Switch with 5mm Detection Distance Inductive Proximity Switch Inductive Sensor 3-Wire Normally Closed","handle":"sn04-n2-npn-proximity-sensor-switch-with-5mm-detection-distance-inductive-proximity-switch-inductive-sensor-3-wire-normally-closed","description":"\u003ch3\u003eSN04-N2 NPN Proximity Sensor Switch with 5mm Detection Distance Inductive Proximity Switch Inductive Sensor 3-Wire Normally Closed\u003c\/h3\u003e \u003cp id=\"b\"\u003eSpecification: Model:SN04-N2 Detection Distance:5mm ± 10% Set Distance :0 - 4mm Delay distance:\u0026lt;10% Detection distance Standard object:Magnetic metal (detection distance decreases for non-magnetic metals) Detection object:Iron 18181mm Response frequency:DC:0.5kHz AC:25Hz Power:DC12 - 24V(6-36V); AC110 - 220V(36 - 250V)50\/60Hz Withstand voltage: AC1000V 50\/60Hz Voltage influence: ±15% Rated voltage, Pulse (PP) less than 10% Consumption current:NP: \u0026lt;13mA, D: \u0026lt;0.8mA, A:\u0026amp;lt ;1.7mA Control output:NP: \u0026lt;300mA, D:\u0026lt;200mA, A:\u0026lt;400mA Circuit protection:A: overvoltage protection NPD: overvoltage protection, reverse polarity protection Temperature range:-25 -+60℃ Insulation resistance:\u0026gt;50MΩ Material:ABS Bearing- and Use Temperature:-30 - +65℃(no ice, no frost) Storage and Use Humidity: 35 - 95%RH List of Packages: 1 Inductive Proximity Switch Note: Actual product color may vary from photo due to light. There may be slight differences in the measurement of the product. Please note that the new type and old type of this product will be shipped randomly. Make sure you don't mind before ordering.\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eWhen the proximity switch is near a target object, it will transmit a control signal.\u003c\/li\u003e \u003cli\u003eHigh sensitivity, fast response, stable performance.\u003c\/li\u003e \u003cli\u003eThis is a normally close proximity switch sensor with 5mm detection distance.\u003c\/li\u003e \u003cli\u003eIt is a component , which is widely used in the automatic control industry for detecting, controlling and non-contact switching.\u003c\/li\u003e \u003cli\u003eNon-contact detection avoids damage to the sensor and the target object.\u003c\/li\u003e \u003c\/ul\u003e","published_at":"2024-04-07T04:23:52+10:00","created_at":"2024-04-07T04:24:02+10:00","vendor":"LiebeWH","type":"Inductive proximity sensors","tags":["industryDE"],"price":15800,"price_min":15800,"price_max":15800,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":49431052222624,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"de-B0C54JZ7ZM","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"SN04-N2 NPN Proximity Sensor Switch with 5mm Detection Distance Inductive Proximity Switch Inductive Sensor 3-Wire Normally Closed","public_title":null,"options":["Default Title"],"price":15800,"weight":700,"compare_at_price":null,"inventory_management":"shopify","barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0C54JZ7ZM.jpg?v=1712447718","\/\/dingoship.com.au\/cdn\/shop\/files\/61_r3RZUSEL.jpg?v=1712427842","\/\/dingoship.com.au\/cdn\/shop\/files\/51ik3moX12L.jpg?v=1712427842","\/\/dingoship.com.au\/cdn\/shop\/files\/51oWufwowpL.jpg?v=1712427842","\/\/dingoship.com.au\/cdn\/shop\/files\/51h_NktTt_L.jpg?v=1712427842","\/\/dingoship.com.au\/cdn\/shop\/files\/51faW1SCTWL.jpg?v=1712427842","\/\/dingoship.com.au\/cdn\/shop\/files\/51bShYFeahL.jpg?v=1712427842"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0C54JZ7ZM.jpg?v=1712447718","options":["Title"],"media":[{"alt":null,"id":33793936621728,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0C54JZ7ZM.jpg?v=1712447718"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/de-B0C54JZ7ZM.jpg?v=1712447718","width":1001},{"alt":null,"id":33790141857952,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61_r3RZUSEL.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61_r3RZUSEL.jpg?v=1712427842","width":1601},{"alt":null,"id":33790141890720,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51ik3moX12L.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51ik3moX12L.jpg?v=1712427842","width":1601},{"alt":null,"id":33790141923488,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1601,"width":1601,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51oWufwowpL.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1601,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51oWufwowpL.jpg?v=1712427842","width":1601},{"alt":null,"id":33790141956256,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51h_NktTt_L.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51h_NktTt_L.jpg?v=1712427842","width":1001},{"alt":null,"id":33790141989024,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51faW1SCTWL.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51faW1SCTWL.jpg?v=1712427842","width":1001},{"alt":null,"id":33790142021792,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51bShYFeahL.jpg?v=1712427842"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51bShYFeahL.jpg?v=1712427842","width":1001}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eSN04-N2 NPN Proximity Sensor Switch with 5mm Detection Distance Inductive Proximity Switch Inductive Sensor 3-Wire Normally Closed\u003c\/h3\u003e \u003cp id=\"b\"\u003eSpecification: Model:SN04-N2 Detection Distance:5mm ± 10% Set Distance :0 - 4mm Delay distance:\u0026lt;10% Detection distance Standard object:Magnetic metal (detection distance decreases for non-magnetic metals) Detection object:Iron 18181mm Response frequency:DC:0.5kHz AC:25Hz Power:DC12 - 24V(6-36V); AC110 - 220V(36 - 250V)50\/60Hz Withstand voltage: AC1000V 50\/60Hz Voltage influence: ±15% Rated voltage, Pulse (PP) less than 10% Consumption current:NP: \u0026lt;13mA, D: \u0026lt;0.8mA, A:\u0026amp;lt ;1.7mA Control output:NP: \u0026lt;300mA, D:\u0026lt;200mA, A:\u0026lt;400mA Circuit protection:A: overvoltage protection NPD: overvoltage protection, reverse polarity protection Temperature range:-25 -+60℃ Insulation resistance:\u0026gt;50MΩ Material:ABS Bearing- and Use Temperature:-30 - +65℃(no ice, no frost) Storage and Use Humidity: 35 - 95%RH List of Packages: 1 Inductive Proximity Switch Note: Actual product color may vary from photo due to light. There may be slight differences in the measurement of the product. Please note that the new type and old type of this product will be shipped randomly. Make sure you don't mind before ordering.\u003c\/p\u003e \u003ch3\u003eProduct Features\u003c\/h3\u003e \u003cul class=\"a\"\u003e \u003cli\u003eWhen the proximity switch is near a target object, it will transmit a control signal.\u003c\/li\u003e \u003cli\u003eHigh sensitivity, fast response, stable performance.\u003c\/li\u003e \u003cli\u003eThis is a normally close proximity switch sensor with 5mm detection distance.\u003c\/li\u003e \u003cli\u003eIt is a component , which is widely used in the automatic control industry for detecting, controlling and non-contact switching.\u003c\/li\u003e \u003cli\u003eNon-contact detection avoids damage to the sensor and the target object.\u003c\/li\u003e \u003c\/ul\u003e"}
