{"id":7126026092704,"title":"UHPPOTE Request to Exit Microwave Sensor Motion Detector for Automatic Door Access Control System Black","handle":"uhppote-request-to-exit-microwave-sensor-motion-detector-for-automatic-door-access-control-system-black","description":"\u003ch3\u003eUHPPOTE Request to Exit Microwave Sensor Motion Detector for Automatic Door Access Control System\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eTechnical Parameters: Technology: Microwave \u0026amp; Microwave\nDisposerFrequency: 24.125GhzTransmitting Power: 20dBm EIRPLaunch Frequency\nDensity: 5mW\/cm2Installation Height: Max. 4m\/13.1ftInstallation Angle: 0~90\ndegree(Lengthways), -30~+30 degree(Lateral)Detection Mode: MotionMin Detection\nSpeed: 5cm(1.97in)\/sPower: 2W(VA)Detection Range: 4(Width)x2(Depth)m \/\n13.1(Width)x6.6(Depth)ft (Installation Height: 2m\/6.6ft)Maximum Voltage:\n42AC\/60V DCMaximum Current: 1AMaximum Switching Power:\n30W(DC)\/60VA(AC)Retention Time: 0.5SGuide Line: 2.5m \/ 8.2ftWorking\nTemperature: -20℃~+55℃ \/ -4℉~131℉Protection Class: IP54Sheel Material: ABS\nplasticColor: BlackAnti-interference Performance: R\u0026amp;TTE1995\/5\/EC, EMC\n89\/366\/EECPower Voltage: 12-24V AC\/DCSize: 120Wx80Hx50D(mm) \/\n4.72\"Wx3.15\"Hx1.97\"D Package Included: 1 x Micro Wave Sensor1 x Connection\nCable1 x English Manual Installation: Please do the installation in the proper\nposition, installation height within 3.5m.Please connect the signal cable with\nthe terminal of automatic door. Brown and Yellow cable: AC\/DC 12V-24VGreen and\nWhite cable: Signal output COM\/NOTake the outer cover off, and fix the\nscrewsFinish the cable connection and get on powerPlease set the detection\nrange and disjunct or accordingly Cover with the lid Safety Instruction:\nRelated part should be operated under low voltage condition. All installation\nprocess and maintenance be carried out by the supplier. Read more\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eTechnology: Microwave \u0026amp; Microwave Disposer\u003c\/li\u003e\n \u003cli\u003eFrequency: 24.125Ghz\u003c\/li\u003e\n \u003cli\u003eTransmitting Power: 20dBm EIRP\u003c\/li\u003e\n \u003cli\u003eLaunch Frequency Density: 5mW\/cm2\u003c\/li\u003e\n \u003cli\u003eMin Detection Speed: 5cm(1.97in)\/s\u003c\/li\u003e\n \u003c\/ul\u003e","published_at":"2021-11-12T22:07:36+11:00","created_at":"2021-11-12T03:28:59+11:00","vendor":"UHPPOTE","type":"Motion Detectors","tags":["cocoon"],"price":25300,"price_min":25300,"price_max":25300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":41334254436512,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B01M99KF69","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"UHPPOTE Request to Exit Microwave Sensor Motion Detector for Automatic Door Access Control System Black","public_title":null,"options":["Default Title"],"price":25300,"weight":270,"compare_at_price":null,"inventory_management":null,"barcode":"0612046379202","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B01M99KF69.jpg?v=1645066294","\/\/dingoship.com.au\/cdn\/shop\/products\/61Ua4O2ihDL.jpg?v=1636648139","\/\/dingoship.com.au\/cdn\/shop\/products\/61TzSK2pwiL.jpg?v=1636648139","\/\/dingoship.com.au\/cdn\/shop\/products\/51SCC-bkWbL.jpg?v=1636648139"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B01M99KF69.jpg?v=1645066294","options":["Title"],"media":[{"alt":null,"id":24017090674848,"position":1,"preview_image":{"aspect_ratio":1.339,"height":1120,"width":1500,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B01M99KF69.jpg?v=1645066294"},"aspect_ratio":1.339,"height":1120,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B01M99KF69.jpg?v=1645066294","width":1500},{"alt":null,"id":23304581447840,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1600,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Ua4O2ihDL.jpg?v=1636648139"},"aspect_ratio":1.0,"height":1600,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61Ua4O2ihDL.jpg?v=1636648139","width":1600},{"alt":null,"id":23304581480608,"position":3,"preview_image":{"aspect_ratio":0.918,"height":1600,"width":1469,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61TzSK2pwiL.jpg?v=1636648139"},"aspect_ratio":0.918,"height":1600,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61TzSK2pwiL.jpg?v=1636648139","width":1469},{"alt":null,"id":23304581513376,"position":4,"preview_image":{"aspect_ratio":1.16,"height":1285,"width":1491,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51SCC-bkWbL.jpg?v=1636648139"},"aspect_ratio":1.16,"height":1285,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51SCC-bkWbL.jpg?v=1636648139","width":1491}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eUHPPOTE Request to Exit Microwave Sensor Motion Detector for Automatic Door Access Control System\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eTechnical Parameters: Technology: Microwave \u0026amp; Microwave\nDisposerFrequency: 24.125GhzTransmitting Power: 20dBm EIRPLaunch Frequency\nDensity: 5mW\/cm2Installation Height: Max. 4m\/13.1ftInstallation Angle: 0~90\ndegree(Lengthways), -30~+30 degree(Lateral)Detection Mode: MotionMin Detection\nSpeed: 5cm(1.97in)\/sPower: 2W(VA)Detection Range: 4(Width)x2(Depth)m \/\n13.1(Width)x6.6(Depth)ft (Installation Height: 2m\/6.6ft)Maximum Voltage:\n42AC\/60V DCMaximum Current: 1AMaximum Switching Power:\n30W(DC)\/60VA(AC)Retention Time: 0.5SGuide Line: 2.5m \/ 8.2ftWorking\nTemperature: -20℃~+55℃ \/ -4℉~131℉Protection Class: IP54Sheel Material: ABS\nplasticColor: BlackAnti-interference Performance: R\u0026amp;TTE1995\/5\/EC, EMC\n89\/366\/EECPower Voltage: 12-24V AC\/DCSize: 120Wx80Hx50D(mm) \/\n4.72\"Wx3.15\"Hx1.97\"D Package Included: 1 x Micro Wave Sensor1 x Connection\nCable1 x English Manual Installation: Please do the installation in the proper\nposition, installation height within 3.5m.Please connect the signal cable with\nthe terminal of automatic door. Brown and Yellow cable: AC\/DC 12V-24VGreen and\nWhite cable: Signal output COM\/NOTake the outer cover off, and fix the\nscrewsFinish the cable connection and get on powerPlease set the detection\nrange and disjunct or accordingly Cover with the lid Safety Instruction:\nRelated part should be operated under low voltage condition. All installation\nprocess and maintenance be carried out by the supplier. Read more\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003eTechnology: Microwave \u0026amp; Microwave Disposer\u003c\/li\u003e\n \u003cli\u003eFrequency: 24.125Ghz\u003c\/li\u003e\n \u003cli\u003eTransmitting Power: 20dBm EIRP\u003c\/li\u003e\n \u003cli\u003eLaunch Frequency Density: 5mW\/cm2\u003c\/li\u003e\n \u003cli\u003eMin Detection Speed: 5cm(1.97in)\/s\u003c\/li\u003e\n \u003c\/ul\u003e"}
