{"id":15201957478560,"title":"waveshare ESP32-S3 1.69inch LCD Display Development Board,240×280 Pixels 262K Color Micro LCD Display with ESP32-S3,Accelerometer and Gyroscope Sensor","handle":"waveshare-esp32-s3-1-69inch-lcd-display-development-board-240-280-pixels-262k-color-micro-lcd-display-with-esp32-s3-accelerometer-and-gyroscope-sensor","description":"\u003ch3\u003ewaveshare ESP32-S3 1.69inch LCD Display Development Board,240×280 Pixels 262K Color Micro LCD Display with ESP32-S3,Accelerometer and Gyroscope Sensor\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures ESP32-S3-LCD-1.69 is a low-cost, high-performance MCU board designed\r\nby Waveshare, embedded with 240MHz dual-core processor, tiny size, with\r\nonboard 1.69inch 262K LCD display, Lithium battery recharge manager, 6-axis\r\nsensor (3-axis accelerometer and 3-axis gyroscope), WiFi\/Bluetooth antenna,\r\nRTC, and so on, which makes it easy for you to develop and integrate it into\r\nproducts quickly. Key features include: Equipped with ESP32-S3R8 Xtensa 32-bit\r\nLX7 dual-core processor, up to 240MHz main frequency Supports 2.4GHz Wi-Fi\r\n(802.11 b\/g\/n) and Bluetooth 5 (LE), with onboard antenna Built in 512KB of\r\nSRAM and 384KB ROM, with onboard 8MB PSRAM and an external 16MB Flash memory\r\nType-C connector, keeps it up to date, easier to use Onboard 1.69inch 240×280\r\npixels 262K display for clear color pictures Built-in ST7789V2 display driver\r\nchip, using SPI communication, effectively saving the IO resources Onboard\r\nQMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting\r\nmotion gesture, counting steps, etc. Onboard PCF85063 RTC chip with reserved\r\nSH1.0 RTC battery header (supports charging) for RTC function requirement\r\nOnboard RST, BOOT and a programmable PWM button for easy custom function\r\ndevelopment Onboard 3.7V MX1.25 lithium battery recharge\/discharge header\r\nReserved 12PIN header of 5 × GPIO, I2C, and UART interfaces, for connecting\r\nperipherals and debugging Supports flexible clock, module power supply\r\nindependent setting, and other controls to realize low power consumption in\r\ndifferent scenarios Package Content ESP32-S3-LCD-1.69 x1 SH1.0 12PIN cable x1\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eESP32-S3 Development Board with 1.69inch Display,Micro LCD Display With ESP32-S3\u003c\/li\u003e\r\n \u003cli\u003eESP32-S3-LCD-1.69,Embedded with ST7789V2 Display Driver Chip, SPI Communication\u003c\/li\u003e\r\n \u003cli\u003eOnboard 1.69inch LCD Screen,IPS Panel, 240280 Resolution, 65K Color, Suitable For Various Application Scenarios\u003c\/li\u003e\r\n \u003cli\u003eWIFI And Bluetooth Support,Supports 2.4 GHz Wi-Fi (802.11 B\/G\/N) And Bluetooth 5 (LE), Onboard Antenna\u003c\/li\u003e\r\n \u003cli\u003eCompact Size, Accelerometer And Gyroscope Sensor\u003c\/li\u003e\r\n \u003c\/ul\u003e","published_at":"2025-10-17T03:03:18+11:00","created_at":"2025-10-17T03:03:12+11:00","vendor":"waveshare","type":"","tags":["electronics_selected_Oct2025"],"price":14300,"price_min":14300,"price_max":14300,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":52929345847456,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B0DB5B29W7","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"waveshare ESP32-S3 1.69inch LCD Display Development Board,240×280 Pixels 262K Color Micro LCD Display with ESP32-S3,Accelerometer and Gyroscope Sensor","public_title":null,"options":["Default Title"],"price":14300,"weight":25,"compare_at_price":null,"inventory_management":"shopify","barcode":"788046389029","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/files\/B0DB5B29W7.jpg?v=1775757600","\/\/dingoship.com.au\/cdn\/shop\/files\/611HZEiztSL.jpg?v=1760630595","\/\/dingoship.com.au\/cdn\/shop\/files\/617oY4SpqPL.jpg?v=1760630595","\/\/dingoship.com.au\/cdn\/shop\/files\/51ASD18WdKL.jpg?v=1760630595","\/\/dingoship.com.au\/cdn\/shop\/files\/61AsUcbeYJL.jpg?v=1760630595","\/\/dingoship.com.au\/cdn\/shop\/files\/61_zt7I2ljL.jpg?v=1760630595","\/\/dingoship.com.au\/cdn\/shop\/files\/61R9San2uuL.jpg?v=1760630595"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/files\/B0DB5B29W7.jpg?v=1775757600","options":["Title"],"media":[{"alt":null,"id":38460596945056,"position":1,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/B0DB5B29W7.jpg?v=1775757600"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/B0DB5B29W7.jpg?v=1775757600","width":1600},{"alt":null,"id":38460596977824,"position":2,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/611HZEiztSL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/611HZEiztSL.jpg?v=1760630595","width":1600},{"alt":null,"id":38460597010592,"position":3,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/617oY4SpqPL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/617oY4SpqPL.jpg?v=1760630595","width":1600},{"alt":null,"id":38460597043360,"position":4,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51ASD18WdKL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/51ASD18WdKL.jpg?v=1760630595","width":1600},{"alt":null,"id":38460597076128,"position":5,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61AsUcbeYJL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61AsUcbeYJL.jpg?v=1760630595","width":1600},{"alt":null,"id":38460597108896,"position":6,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61_zt7I2ljL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61_zt7I2ljL.jpg?v=1760630595","width":1600},{"alt":null,"id":38460597141664,"position":7,"preview_image":{"aspect_ratio":1.333,"height":1200,"width":1600,"src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61R9San2uuL.jpg?v=1760630595"},"aspect_ratio":1.333,"height":1200,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/files\/61R9San2uuL.jpg?v=1760630595","width":1600}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003ewaveshare ESP32-S3 1.69inch LCD Display Development Board,240×280 Pixels 262K Color Micro LCD Display with ESP32-S3,Accelerometer and Gyroscope Sensor\u003c\/h3\u003e\r\n\u003cp id=\"b\"\u003eFeatures ESP32-S3-LCD-1.69 is a low-cost, high-performance MCU board designed\r\nby Waveshare, embedded with 240MHz dual-core processor, tiny size, with\r\nonboard 1.69inch 262K LCD display, Lithium battery recharge manager, 6-axis\r\nsensor (3-axis accelerometer and 3-axis gyroscope), WiFi\/Bluetooth antenna,\r\nRTC, and so on, which makes it easy for you to develop and integrate it into\r\nproducts quickly. Key features include: Equipped with ESP32-S3R8 Xtensa 32-bit\r\nLX7 dual-core processor, up to 240MHz main frequency Supports 2.4GHz Wi-Fi\r\n(802.11 b\/g\/n) and Bluetooth 5 (LE), with onboard antenna Built in 512KB of\r\nSRAM and 384KB ROM, with onboard 8MB PSRAM and an external 16MB Flash memory\r\nType-C connector, keeps it up to date, easier to use Onboard 1.69inch 240×280\r\npixels 262K display for clear color pictures Built-in ST7789V2 display driver\r\nchip, using SPI communication, effectively saving the IO resources Onboard\r\nQMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting\r\nmotion gesture, counting steps, etc. Onboard PCF85063 RTC chip with reserved\r\nSH1.0 RTC battery header (supports charging) for RTC function requirement\r\nOnboard RST, BOOT and a programmable PWM button for easy custom function\r\ndevelopment Onboard 3.7V MX1.25 lithium battery recharge\/discharge header\r\nReserved 12PIN header of 5 × GPIO, I2C, and UART interfaces, for connecting\r\nperipherals and debugging Supports flexible clock, module power supply\r\nindependent setting, and other controls to realize low power consumption in\r\ndifferent scenarios Package Content ESP32-S3-LCD-1.69 x1 SH1.0 12PIN cable x1\u003c\/p\u003e \r\n\r\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\r\n \u003cul class=\"a\"\u003e\r\n \u003cli\u003eESP32-S3 Development Board with 1.69inch Display,Micro LCD Display With ESP32-S3\u003c\/li\u003e\r\n \u003cli\u003eESP32-S3-LCD-1.69,Embedded with ST7789V2 Display Driver Chip, SPI Communication\u003c\/li\u003e\r\n \u003cli\u003eOnboard 1.69inch LCD Screen,IPS Panel, 240280 Resolution, 65K Color, Suitable For Various Application Scenarios\u003c\/li\u003e\r\n \u003cli\u003eWIFI And Bluetooth Support,Supports 2.4 GHz Wi-Fi (802.11 B\/G\/N) And Bluetooth 5 (LE), Onboard Antenna\u003c\/li\u003e\r\n \u003cli\u003eCompact Size, Accelerometer And Gyroscope Sensor\u003c\/li\u003e\r\n \u003c\/ul\u003e"}
