{"id":7409536696480,"title":"Yosoo Health Gear Liquid Level Controller GRL8-02 Automatic Water Level Controller Relay Water Level Controller 24Vwith DIN Rail Mount for Pool Tank Liquid Level Monitoring","handle":"yosoo-health-gear-liquid-level-controller-grl8-02-automatic-water-level-controller-relay-water-level-controller-24vwith-din-rail-mount-for-pool-tank-liquid-level-monitoring","description":"\u003ch3\u003eYosoo Health Gear Liquid Level Controller GRL8-02 Automatic Water Level Controller Relay Water Level Controller 24Vwith DIN Rail Mount for Pool Tank Liquid Level Monitoring\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification:Model: GRL8-02Function: 2 or 1 level control modePower terminal:\nA1-A2Rated power supply voltage: AC\/DC 24-240V(50-60Hz)Power consumption:\nmaximum. 2VASensitivity adjustment range: 5-100kΩSupply voltage tolerance:\n-15%; +10%Voltage in electrodes: maximum. AC 5VCurrent in electrodes: maximum.\n0.1mAResponse time: maximum. 400msElectrode cable allows distributed acitance\n(maximum): 800nF-100nFElectrode cable length: ≤100mAction delay time: 0.1s-10s\n(adjustable)Setting accuracy: 10%Output contact parameters: 1 x SPDT, 10A\/AC1,\n250VAC\/24VDCMinimum switching power: 500mWPower indicator: Green LEDOutput\nindication: Red LEDMechanical life: 1x107Electrical life(resistive load):\n1x106Reset time: maximum 200msWorking temperature: -20℃~55℃Mounting method:\n35mm DIN railMounting altitude: ≤2000mWiring ability: 1x2.5mm2or\n2x1.5mm2Dimensions: 901864mm \/ 3.540.712.52inWeight: Approx. 82g\/2.9oz\nPackageList:1 Liquid Level Control Relay\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e[Specification]: Output: 1 x SPDT, 10A\/AC1, 250VAC\/24VDC; Response time: maximum. 400ms\u003c\/li\u003e\n \u003cli\u003e[Application]: This water level controller is designed for monitoring liquid level in pool, well, water tower, reservoirs, tanks, etc\u003c\/li\u003e\n \u003cli\u003e[Sensitivity \u0026amp; Delay time Adjustable]: This liquid level control relay can be adjusted to meet your different needs; Action time delay (0.1-10S); Adjust sensitivity by a knob (5-100k)\u003c\/li\u003e\n \u003cli\u003e[LED Indicators]: Relay status is indicated by Green \u0026amp; Red LED; Power indicator: Green LED; Output indication: Red LED\u003c\/li\u003e\n \u003cli\u003e[Easy to Install]: The liquid level controller is compact to install by 35mm DIN rail mount\u003c\/li\u003e\n \u003c\/ul\u003e\n\n","published_at":"2022-06-09T20:11:47+10:00","created_at":"2022-06-09T20:11:54+10:00","vendor":"Yosoo Health Gear","type":"Liquid Level Sensors","tags":["dingo"],"price":17700,"price_min":17700,"price_max":17700,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42173022372000,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"B08HWX85QT","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Yosoo Health Gear Liquid Level Controller GRL8-02 Automatic Water Level Controller Relay Water Level Controller 24Vwith DIN Rail Mount for Pool Tank Liquid Level Monitoring","public_title":null,"options":["Default Title"],"price":17700,"weight":80,"compare_at_price":null,"inventory_management":null,"barcode":null,"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/dingoship.com.au\/cdn\/shop\/products\/B08HWX85QT.jpg?v=1654820643","\/\/dingoship.com.au\/cdn\/shop\/products\/51Jbb2M-zSL.jpg?v=1654769514","\/\/dingoship.com.au\/cdn\/shop\/products\/51WpWzAfVpL.jpg?v=1654769514","\/\/dingoship.com.au\/cdn\/shop\/products\/51V_6GOblKL.jpg?v=1654769514","\/\/dingoship.com.au\/cdn\/shop\/products\/513L9n5bDSL.jpg?v=1654769514","\/\/dingoship.com.au\/cdn\/shop\/products\/51TQSmcROTL.jpg?v=1654769514","\/\/dingoship.com.au\/cdn\/shop\/products\/61WHG8pbuHL.jpg?v=1654769514"],"featured_image":"\/\/dingoship.com.au\/cdn\/shop\/products\/B08HWX85QT.jpg?v=1654820643","options":["Title"],"media":[{"alt":null,"id":24832167805088,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B08HWX85QT.jpg?v=1654820643"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/B08HWX85QT.jpg?v=1654820643","width":1001},{"alt":null,"id":24827665186976,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51Jbb2M-zSL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51Jbb2M-zSL.jpg?v=1654769514","width":1001},{"alt":null,"id":24827665219744,"position":3,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51WpWzAfVpL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51WpWzAfVpL.jpg?v=1654769514","width":1001},{"alt":null,"id":24827665252512,"position":4,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51V_6GOblKL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51V_6GOblKL.jpg?v=1654769514","width":1001},{"alt":null,"id":24827665285280,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/513L9n5bDSL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/513L9n5bDSL.jpg?v=1654769514","width":1001},{"alt":null,"id":24827665318048,"position":6,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51TQSmcROTL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/51TQSmcROTL.jpg?v=1654769514","width":1001},{"alt":null,"id":24827665350816,"position":7,"preview_image":{"aspect_ratio":1.0,"height":1001,"width":1001,"src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61WHG8pbuHL.jpg?v=1654769514"},"aspect_ratio":1.0,"height":1001,"media_type":"image","src":"\/\/dingoship.com.au\/cdn\/shop\/products\/61WHG8pbuHL.jpg?v=1654769514","width":1001}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003ch3\u003eYosoo Health Gear Liquid Level Controller GRL8-02 Automatic Water Level Controller Relay Water Level Controller 24Vwith DIN Rail Mount for Pool Tank Liquid Level Monitoring\u003c\/h3\u003e\n\u003cp id=\"b\"\u003eSpecification:Model: GRL8-02Function: 2 or 1 level control modePower terminal:\nA1-A2Rated power supply voltage: AC\/DC 24-240V(50-60Hz)Power consumption:\nmaximum. 2VASensitivity adjustment range: 5-100kΩSupply voltage tolerance:\n-15%; +10%Voltage in electrodes: maximum. AC 5VCurrent in electrodes: maximum.\n0.1mAResponse time: maximum. 400msElectrode cable allows distributed acitance\n(maximum): 800nF-100nFElectrode cable length: ≤100mAction delay time: 0.1s-10s\n(adjustable)Setting accuracy: 10%Output contact parameters: 1 x SPDT, 10A\/AC1,\n250VAC\/24VDCMinimum switching power: 500mWPower indicator: Green LEDOutput\nindication: Red LEDMechanical life: 1x107Electrical life(resistive load):\n1x106Reset time: maximum 200msWorking temperature: -20℃~55℃Mounting method:\n35mm DIN railMounting altitude: ≤2000mWiring ability: 1x2.5mm2or\n2x1.5mm2Dimensions: 901864mm \/ 3.540.712.52inWeight: Approx. 82g\/2.9oz\nPackageList:1 Liquid Level Control Relay\u003c\/p\u003e \n\n\u003ch3\u003eProduct Features\u003c\/h3\u003e\n \u003cul class=\"a\"\u003e\n \u003cli\u003e[Specification]: Output: 1 x SPDT, 10A\/AC1, 250VAC\/24VDC; Response time: maximum. 400ms\u003c\/li\u003e\n \u003cli\u003e[Application]: This water level controller is designed for monitoring liquid level in pool, well, water tower, reservoirs, tanks, etc\u003c\/li\u003e\n \u003cli\u003e[Sensitivity \u0026amp; Delay time Adjustable]: This liquid level control relay can be adjusted to meet your different needs; Action time delay (0.1-10S); Adjust sensitivity by a knob (5-100k)\u003c\/li\u003e\n \u003cli\u003e[LED Indicators]: Relay status is indicated by Green \u0026amp; Red LED; Power indicator: Green LED; Output indication: Red LED\u003c\/li\u003e\n \u003cli\u003e[Easy to Install]: The liquid level controller is compact to install by 35mm DIN rail mount\u003c\/li\u003e\n \u003c\/ul\u003e\n\n"}
